Square D Grey Metal Indoor 100 A Main Lugs Panel Load Centre / 12 Spaces and 24 Circuits
Article #332076380
Model #CQO12L100PGC
124
.
99
This item is not currently available for immediate purchase, but can be ordered by visiting the selected store.
Most orders will ship next business day. Some orders may take up to 7-14 days (where inventory is not available in store). Delivery time may vary due to factors beyond our control. You will receive an email when your order has shipped. See all details.
Gift cards are delivered 2 to 5 days following the confirmation of your order in major urban areas and within 7 business days for remote locations. Gift Cards can be delivered across Canada, except the Yukon, Nunavut, Northwest Territories and Northern Quebec. See all details.
Sold online only. Total price includes delivery without any additional fees. Delivery time may vary due to factors beyond the control of RONA. Some restrictions may apply for remote areas. Signature may be required. Deliveries are made to threshold or curbside only, subject to carrier discretion.
The earliest delivery date displayed is only an estimate. The actual delivery date may change based on availability of products, or due to other circumstances beyond our control. Appliance delivery date can be selected in the checkout. If there is no option to schedule your appliance delivery, our team will contact you to schedule a delivery within 24 hours. Learn More.
RONA's third-party partners handle all express deliveries. Only available for select in-store items in sufficient stock at the participating selected store. Delivery address must be within delivery zone of the selected participating store. Weight limit of 1,475 Kg (3,250 lbs) per order. Not available on national/provincial holidays. Service may not be available due notably high in-store traffic, bad weather conditions or any other situation affecting the availability of the service. See all details.
Our expert center will contact you to schedule a delivery within 24 hours. The delay for delivery is an estimate and may vary according to the availability of products, or due to other circumstances beyond our control. Delivery prices only include curbside delivery, except for appliances. Delivery service is only available within a 50 km radius from the selected store (75 km for RONA+ stores). Additional charges may apply for installation. We will not leave deliveries at an unattended site – note that additional delivery charges may apply for subsequent delivery attempts. See all details.
Add to Cart
Warranty
Limited lifetime
Add to Cart
AI-Generated answer
Description
Square D load centres are designed for residential and industrial use to protect electrical systems, equipment and people. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO load centre is supplied with a convertible main that is rated at 100A 240 VAC single phase. This QO load centre provides a 65 kA breaking capacity. This system provides 12 spaces in a NEMA 1 indoor enclosure with a combination flush/surface indoor cover. A ground bar is included but is to be field installed.
- Single phase, 3 wires, 120/240 VAC
- 12 spaces, expandable up to 24 circuits using tandem QO circuit breakers
- Type 1 indoor enclosure with flush/surface mount trim suitable for all mountings
- CSA approved for vertical, horizontal or inverted mounting
- Compatible with copper and aluminum conductors
- Main wire gauge: AWG/kCM Al/Cu: No. 4-1
Product specifications
Series Name
N/A
Safety Listing
CSAus safety listing
Type
Rectangular
Color/Finish Family
Gray
Number of Knockouts/Holes
0
Cover Included
Yes
Country of Origin
United States
Package Quantity
1
Warranty
Limited lifetime
Maximum Weight Supported(lbs.)
15
Weight(lb)
17.84
Assembled Depth(in)
15.81
Assembled Height(in)
19.75
Assembled Width(in)
5.25
Construction Type
N/A
Fire Rating in Hours
NA
GFCI Receptacle Included
No
Knockout Size
N/A
Low Voltage
Yes
Material
Metal
Mounting Type
In-wall
Number of Gangs
0
Old or New Work
New work/Old work
Sub Type
N/A
Use Location
Interior
Weatherproof
No
File/Certification Number
CSA22.2
