Rinnai I-SERIES+ IP090160C Combi Boiler 160K-BTU/90K-BTU 7.9-GPM NG/LP Convertible
Article #332062883
Model #IP090160C
This item is not currently available for immediate purchase, but can be ordered by visiting the selected store.
Add to Cart
Warranty
12-year limited
Add to Cart
Description
This item allows for simultaneous delivery of domestic hot water and space heating, 4 built-in zones and 7 heating reset curves.
- 96% AFUE for significant energy savings
- Smart Connect™ connects to the I-SERIES Plus™ via Bluetooth; use the Rinnai Central™ App for quick, simplified tankless water heater set-up and registration
- Smart Sense™ Adaptive Gas Valve Technology; adjusts to either natural gas or liquid propane Gas for optimal combustion; no conversion kit required
- Low NOx Emissions (≤ 20ppm) in Compliance with SCAQMD
- IP090160C TDR (Turndown Ratio) 6.0:1
- Industry leading 2-in venting up to 75-ft
- 90K Heating BTU Input / Domestic hot water 160K BTU
- 7.9-gal/min maximum
- Warranty is standard for residential; 12 yrs HEX / 5 yrs parts / 1 yr labour
Product specifications
ENERGY STAR Certified
Yes
Country of Origin
Japan
Fuel Source
Natural gas
Commercial/Residential
Residential
Base Warranty Labor(Months)
12
Base Warranty Parts(Months)
60
Warranty
12-year limited
Maximum Weight Supported(lbs.)
25
Voltage
120
Weight(lb)
73
BTU Rating
160000
Depth(in)
11.5
Height(in)
30.6
High Efficiency
Super high efficiency
Hub Required
No
Ignition Type
Electronic
Remote Wireless Thermostat
Not available
Vent Type
Direct vent
Width(in)
18.5
Works with Apple HomeKit
No
Works with Android
Yes
File/Certification Number
3554070
Works with SmartThings
No
Works with iOS
Yes
Bluetooth Compatibility
Yes
Safety Listing
CSA safety listing
Series Name
I-Series
App Compatibility
Yes
Voice Controlled
No
Wi-Fi Compatibility
Yes
Works with Amazon Alexa
Yes
Works with the Google Assistant
Yes
