Description
Leave the decisions to your dishwasher with the Sensor cycle that automatically adjusts wash and dry settings to deliver precise results. This ENERGY STAR® qualified dishwasher holds 15 place settings and cleans quietly at 53 dBA. It also provides more room for dishes in the lower rack with the AnyWare™ Plus silverware basket that sits in the door or on the front of the rack to free up rack space. This dishwasher also offers a convenient 1-hour wash option.


Ecological Attributes
This dishwasher is ENERGY STAR® certified to save up to 12% in energy and 30% in water.
Product specifications
Amperage
15 A
Color
Black
Height
Minimum size: 33.5-in (85.09 cm); maximum size: 34.5-in (87.63 cm)
Width
Nominal size: 24-in (60.96 cm); actual size: 23.88-in (60.64 cm)
Sound Level
53 dBA
Depth
24.5-in (62.23 cm)
Type
Built-in dishwasher
Voltage
120 V
Weight
56 lbs (25.4 kg)
Warranty Labour
1-year limited warranty
Warranty Parts
1-year limited warranty
Energy Consumption
260 kWh/yr
Sabbath Mode (Y/N)
No
Tub
Tall tub design, plastic
Delayed Start (Y/N)
Yes
Place Setting Capacity
15
Wash System
AccuSense®
Cycles
(5) 1-Hour Wash, Heavy, Normal, Sensor Wash, Soak & Clean
Options
4-Hour Delay, Control Lock, Heated Dry, Hi Temp Wash, Sani Rinse®
Steam Cleaning (Y/N)
No
Cutlery Basket
AnyWare™ Basket
Rack
Nylon - 1 x 11" cup shelf, 2 x no flip clips
Food Disposer (Y/N)
No
Installation Kit
Kit # 3270-600
Leak Sensor (Y/N)
No
Soil Sensor (Y/N)
Yes
Control Location
Front
Control Type
Electronic Touch
Handle Type
Pocket handle
Lock System (Y/N)
Yes
Adjustable Tines (Y/N)
No
Install Type
Built-In
Colour Family
Black
Energy Star
Yes
Wi-Fi Connection
No
Useful information
DELIVERY AND INSTALLATION
Our experts are dedicated to ensuring your new appliance is delivered with the utmost care.
Learn More
Credit available
Frequently bought together
You may also like
Does this model (WDF540PADW) allow side mounting for granite counter top?
Hi Juan,
Yes, that is possible. Please refer to page 17 from the Installation Instructions Guide:
"
– For countertops that are marble, granite, or another
hard surface, use Side Attachment: go to Step 37
NOTE: If the gap between the top of the door and the
underside of the counter top is tight (less than 1
/4" [6,35 mm]),
we suggest using Side Attachment to keep from scratching
the User Interface or console with the anchor screws."
Here is a link for your reference: https://www.whirlpool.ca/content/dam/global/documents/201709/InstallationInstructions-W10806908-RevC.pdf
Thanks for your question,
Whirlpool Central Advisors.
Date published: 2020-08-09
Is the tub stainless steel?
Hi Balone,
The Tub Material on this model is Plastic.
Thanks for your question,
Whirlpool Central Advisors.
Date published: 2020-08-06
Is the interior stainless steel?
No,the interior is plastic
Date published: 2019-08-08
What is the noise level of this machine ?How many cycles?
Five cycles and super quiet
Date published: 2019-07-05
Can you use the silverware holder in the racks
Yes. We prefer to use it mounted to the door so we have the extra room in the rack.
Date published: 2019-07-12
what is the decibel level on this machine?
I do not know the actual decibel level, but I would give it a scale of 1 to 10, 10 being the noisiest,1 being the least, I would give it a 3.5
Date published: 2019-05-29
Is the height adjustable?
yes but only about 1/2 inch and it is very quiet
Date published: 2019-05-11
Is this stainless steel inside?
Hi Marionw, the WDF540PADW has a plastic tub with Nylon racks. This dishwasher also offers you Cycle Memory which allows you to quickly start your dishwasher with one button. It automatically remembers the last cycle you picked so it's stored and ready to go. Hope this helps, thank you for your question!
Date published: 2019-01-05
24" Dishwasher with Sensor Cycle - Black is rated
out of
5 by
2926.
Rated 5 out of
5
by
jman from
Excellent Heavily Used Dishwasher
We have 3 children (one being a toddler and infant twins) and we use this dishwasher several times a day with bottles, sippy cups, and normal household dishes. This dishwasher cleans very well, a lot better than our old one, and holds a lot more dishes than our old one. We looked at and researched a lot of dishwashers before selecting this one. The guy at lowes suggested this one after we discussed our children's ages and usage requirements. We have had this diswaher for several months now and still love it. I bought this diswasher and the $20 kit, and I was washing dishes in less than two hours. Intall was quick and easy.
Date published: 2015-04-17
Rated 3 out of
5
by
Fishsmom from
Disappointed
I bought this about a month ago. I was very excited to have a Whirlpool as I have had such good luck with the brand in the past. I am disappointed with my new dishwasher. It will not dry my dishes unless I open the door as soon as the cycle finishes. My house is very humid to start with and this adds to the humidity problem. Cannot leave the silverware rack in the door....have to dry them because the water runs down the door and keeps them wet. Doesn't hold as many dishes as my old cheap one because it won't clean unless there is only one layer of dirty dishes. You also HAVE to use Jet Dry! The positive thing is that it is quiet!
Date published: 2015-08-01
Rated 5 out of
5
by
Anonymous from
Outstanding dishwasher, great value
We bought the Whirlpool dishwasher to replace an older dishwasher. After looking at just about every dishwasher made, and all the different features as well as prices, we found that the Whirlpool had many of the features found only in higher priced machines. Since installed, we just love it! Not only is it full of great features, but it so much quieter (even though model we chose did not have the lowest noise rating) than our old dishwasher. And the racks are so roomy, and convenient. And so far, we've found this Whirlpool cleans even the heaviest of cleaning jobs with ease. A great product, and even made in the USA! Keep it up Whirlpool!
Date published: 2015-05-31
Rated 5 out of
5
by
Natx from
Very satisfied with our new dishwasher
(This review was collected as part of a promotion.) We've been using our new dishwasher for a few weeks now and are very impressed with it. It is nice looking and quiet. If we use a rinsing liquid, the dishes come out extremely clean and dry. I haven't seen my wine glasses look so spotless. KEep in mind though, that you have to use a rinsing liquid to get this effect (and this is consistent with the manufacturer's instructions). If you don't, the dishes can come out very wet.
Also, the cutlery rack is a bit awkward for us because half the slots are too small for our cutlery to fit in. We can lift up the covers though to solve that issue.
Date published: 2018-09-10
Rated 5 out of
5
by
Shhh from
Super Quiet - shh don't wake the baby!
(This review was collected as part of a promotion.) I purchased one for my house after purchasing and installing the exact same model of Whirlpool dishwasher in our church kitchen 2 weeks earlier. Our old 23 year old model was still cleaning the dishes but the white Corelle-type cups on the top rack were coming out with what looked like tea stains on the inside only. I decided to take these cups to the church dishwasher and use our same detergent. The dishwasher was amazingly super quiet and in one wash all of the staining was gone. We have had ours only for one week and used it for 2 loads and everything is impressive! So happy with this purchase:)
Date published: 2018-10-31
Rated 5 out of
5
by
Diane, working mom of 2 teenagers from
Great Dishwasher!
We bought this dishwasher a few months ago to replace a 20 year old Whirlpool dishwasher that finally gave out, and are very happy with our purchase. As long as you follow manufacturer's instructions (clearly states to use a rinse agent), all functions work as expected, and it does a great job in cleaning! Our dishes are clean and dry, and are not 'wet' which I've read on other reviews. We have well water, with a whole-house filtration system and a water softener. Must say the dishwasher looks very nice in our kitchen as well - thanks for the design Whirlpool! Love that this dishwasher is quieter that the one we replaced as well!
Date published: 2016-05-25
Rated 5 out of
5
by
Anonymous from
Flexible
This is a good dishwasher for a good price. It gets the dishes clean. It has a cycle to please everyone, it seems. These include water savers that take a long time, short cycles that use more water, and cycles that will sterilized dishes with ultra hot water. The flatware tray is easy to remove and replace. It is very quiet, really hard to hear. My only gripe is that it has not audible signal in the short cycle to let you know it is done. I like to open the dishwasher when it is done to let the dishes air dry, but it is hard to tell when the cycle I use is over. It would be nice if there were a buzzer or some other audible signal.
Date published: 2015-12-06
Rated 5 out of
5
by
Anonymous from
Great price Great Dishwasher
I bought this dishwasher a few weeks ago. I host large family/friends meals and was tired of a couple of us always spending our visiting time doing the dishes.Although we would have great dish washing conversations the years of hosting, cooking most of the meal and then doing the dishes was getting to be too much of a chore. I love my dishwasher. Even having to do two loads is acceptable. The price was reasonable. It cleans very well. I have tried all but the sani cycle. It uses very little water.It was so wonderful to have "Whirly" do the dishes so everyone was able to relax after supper. I am looking forward to more family and friend get togethers.
Date published: 2015-11-15
